Hidden Hydraulic Handbrake BMW E9X E90 E91 E92 E93 in Ashtray

This E9X hidden hydraulic handbrake is a vertical hydraulic handbrake for the BMW 3 Series E90, E91, E92 and E93 that you tuck away in the ashtray space. The lever is quick to remove, so nothing stands out on the road. At the circuit or on a drift day, you screw the lever back on in a few turns.

Ideal for anyone who drives their E9X every day as well as using it for drifting or trackdays, and wants to keep a normal-looking interior. The system works with a hydraulic OBP cylinder and has a black finish.

Key benefits of the E9X hidden hydraulic handbrake

• Hidden mounting in the ashtray space
• Quick-release lever thanks to a specially modified thread
• Vertical layout with a hydraulic OBP cylinder
• Mounting holes that match the original holes in the tunnel
• Can be connected to the existing brake system or as an additional, separate brake circuit
• No ratchet, so no locking while drifting
• Colour: black

Suitable for

BMW 3 Series E9X

• BMW E90 saloon (E90 generation)
• BMW E91 Touring
• BMW E92 coupé
• BMW E93 convertible

Technical specifications

• Item number: 0326
• Type: vertical hydraulic handbrake, hidden mounting
• Cylinder: OBP
• Lever: quick-release via a modified thread
• Ratchet: none
• Mounting: plate around the gear lever on the original holes in the tunnel, lever through the ashtray
• Colour: black
• Weight (shipping): 3 kg
• Adapters for a separate brake circuit: available separately

Installation and delivery

To fit the E9X hidden hydraulic handbrake, part of the ashtray space has to be cut away. The black mounting plate fits around the gear lever and has mounting holes that match the original holes in the tunnel. The lever then sticks up through the ashtray. Depending on the version of the car, the plastic on the inside of the tunnel may need to be trimmed slightly. This cannot be seen from the outside.

You can include the E9X hidden hydraulic handbrake in the existing brake system or build an additional, independent brake circuit with it. The adapters for this are available separately. If you work on the brake system, bleed it carefully and check all connections for leaks before you drive. If in doubt, have the work done by an experienced mechanic.

See more systems in our hydraulic handbrake category. If you would rather have the handbrake in the original location, take a look at the hidden hydraulic handbrake for the E90, E91, E92 and E93 in the original location.

Out of sight on the road, a full hydraulic handbrake on the track in a few turns.

Why choose this E9X hidden hydraulic handbrake?

A fixed hydraulic handbrake stands out and gets in the way in daily use. This solution disappears into the ashtray space and you unscrew the lever in a few turns. That way you keep a tidy interior and still have a handbrake that is ready for drifting. Because there is no ratchet, the rear wheels lock for exactly as long as you pull.

Frequently asked questions

Do I have to modify the interior?

Yes, part of the ashtray space is cut away. On some versions the plastic in the tunnel also has to be trimmed slightly, but you will not see that from the outside.

Does the E9X hidden hydraulic handbrake have a ratchet?

No. It has no ratchet or lock and is therefore not intended as a parking brake.

Can I install a separate brake circuit?

Yes. You can connect the handbrake to the existing brake system or build an additional circuit. The adapters for this are available separately.

How quickly does the lever of the E9X hidden hydraulic handbrake come off?

Thanks to the modified thread, you remove the lever in a few turns and put it back on just as quickly.

Does it fit all body styles?

It is intended for the E9X saloon, Touring, coupé and convertible. If you are unsure about a Touring, please contact us.
