Reversed Hydraulic Handbrake Mounting Plate Driver Side

This mounting plate is intended for a reversed hydraulic handbrake, a handbrake mounted the other way round, and places it on the driver side of the centre tunnel. This puts the lever close to your hand and keeps your reaction time as short as possible. The plate is made of 5 mm steel, black, and fits all BMW tunnels.

You usually choose a reversed handbrake when the standard layout does not fit your interior well or when you want the controls arranged differently. This base is made for exactly that layout, with the holes already in the right place.

Key benefits of this plate for a reversed hydraulic handbrake

• Made specifically for handbrakes mounted the other way round
• Driver side: the lever sits close to you, so you react faster
• Fitted without welding, so installation is simple
• 5 mm steel for a stiff base
• Mounting holes are already in place
• Suitable for all reversed handbrakes and shifters from the same product line
• Fits all BMW tunnels and often other makes too

Suitable for

BMW 3 Series with the standard centre tunnel

• BMW 3 Series E30
• BMW 3 Series E36 and E36 Compact
• BMW 3 Series E46
• BMW 3 Series E90, E92 and E93
• Other makes: often a good fit thanks to the simple shape, but do check the available space

Technical specifications

• Item number: 0092rev
• Version: for a reversed hydraulic handbrake
• Position: driver side of the tunnel
• Material: steel
• Plate thickness: 5 mm
• Colour: black
• Mounting: bolted on through the mounting holes, no welding needed
• Weight: 1.58 kg

Installation and delivery

Start by clearing the tunnel: centre console out, carpet to one side. Place the handbrake loosely on the plate, hold the assembly in position and check from the driving position that the lever is comfortable to operate. Then mark the holes, drill them and bolt the plate down with bolts, washers and locking nuts.

Before drilling, check what runs underneath the tunnel. Route the brake lines so that they do not rub anywhere and bleed the system after connecting it. With a reversed hydraulic handbrake, the line often runs differently from a normal layout, so take your time for a tidy route.

You will find handbrakes, cylinders and other parts in the hydraulic handbrake category. If you use a normal, non-reversed handbrake on the driver side, choose the standard mounting plate for the driver.

The right base for a reversed handbrake: stiff, pre-drilled and no welding.

Why choose this plate for your reversed hydraulic handbrake?

A reversed handbrake needs a different base from a standard one. With this plate you do not have to draw or cut anything yourself. You get a sturdy base of 5 mm steel that fits every BMW tunnel and puts the lever close to the driver. The result is a tight, sturdy setup that gives you the same feel every time you pull the lever.

Frequently asked questions

What does reversed mean for a handbrake?

With a reversed hydraulic handbrake, the handbrake is mounted the other way round compared with the standard layout. This plate is made for those reversed handbrakes.

Does a normal handbrake also fit this plate?

The plate is intended for reversed handbrakes. For a standard handbrake on the driver side, we have a separate mounting plate.

Does the plate have to be welded in?

No, you bolt it on. The mounting holes are already there.

Which cars does it fit?

All BMW tunnels, such as those of the E30, E36, E36 Compact, E46 and E90/E92/E93. Thanks to its simple shape, it can often be used in other makes too.

Can I also mount a shifter on the plate?

Yes. The plate is suitable for the reversed handbrakes and the shifters from the same product line, so you mount both on a sturdy base.

How heavy and how thick is the plate?

It is 5 mm thick and weighs 1.58 kg.
