AST Multipoint Weld-in Roll Cage BMW 2002 V4

The AST Multipoint Weld-in Roll Cage BMW 2002 V4 is a full roll cage for the BMW 2002 with 2-door coupé bodywork. This Multipoint BMW 2002 V4 is the top model of the multipoint range: ten welded mounting points, the full set of bars and a harness bar to which the shoulder straps are attached.

The cage is designed and built by AST Roll Cages in Spain, for drivers who are turning their classic two-door BMW into a fully fledged competition car and are looking for maximum rigidity.

Key benefits

• The most substantial version AST offers in the multipoint range for the 2002.
• Ten welded mounting points make the cage a load-bearing part of the bodyshell.
• Harness bar as a correct mounting point for a four-point or six-point harness.
• Extra diagonal brace that further stiffens the main hoop.
• Door bars and front bars cover both the sides and the front section.
• E355 steel with 45 mm for the main hoop and 40 mm for the rest of the structure.
• Complete weld-in kit with gussets, reinforcement plates, mounting hardware, documentation, fitting instructions and a sticker set.

Suitable for

BMW 2002, E10 chassis, 2-door Coupé

• BMW 2002 (E10) 2-door Coupé, model years 1966 to 1977
• Type: multipoint weld-in roll cage, version V4
• Drifting, track use and rallying

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN00243
• Sunroof: for roofs without a sunroof
• Headlining: for roofs without headlining
• Rear anchorage: in the rear suspension area
• Rear structure layout: X design
• Type: full roll cage, multipoint weld-in (permanent)
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot plates: 3 mm steel, custom-designed for each car
• Mounting: 10 welded mounting points on the bodyshell
• Weight: 71 kg (manufacturer’s figure)
• Finish: unpainted weld-in kit
• Included: weld-in kit, gussets, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set
• FIA homologation numbers: 5258, 5331, 1550, 5445 and 1663 (as stated by AST Roll Cages, for the BMW 2002, 2002 ti, 2002 tii and 2002 Turbo)

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. Strip the interior out of the car completely and fix the seat position beforehand, because the height of the harness bar depends on the driver’s shoulder height.

A BMW 2002 doesn’t get any more rigid than this: ten welded mounting points, the full set of bars and a harness bar in one structure.

Why choose this Multipoint BMW 2002 V4 roll cage?

If you really drive a classic at pace, you want no doubts about its construction. This version combines the maximum number of welded mounting points with every bar AST designs for the E10, so you won’t need to weld anything on later. AST digitises the bodyshell with laser scanners and designs the cage in 3D, so that every part falls into place even with this many tubes.

Frequently asked questions

What exactly will I receive?

The Multipoint BMW 2002 V4 comes as an unpainted weld-in kit with tubes cut to size, gussets, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and a sticker set. You can do the welding and painting yourself or have your workshop do it.

Is this roll cage FIA-homologated?

For this product, AST Roll Cages lists FIA homologation numbers 5258, 5331, 1550, 5445 and 1663 and states that the structure complies with FIA Appendix J for the BMW 2002, 2002 ti, 2002 tii and 2002 Turbo. Always check with the technical committee of your own class.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
