AST Removable Half Roll Cage BMW E34 Sedan V1

The AST Removable Half Roll Cage BMW E34 Saloon V1 is a half roll cage for the BMW 5 Series E34 with 4-door saloon bodywork. This removable half cage E34 Saloon V1 is the basic version: a main hoop with backstays that protects the rear compartment and can be taken back out of the car via the connecting sleeves.

The cage is designed and built by AST Roll Cages in Spain, for drivers who take their E34 to the circuit or the drift track and want to keep the car perfectly usable the rest of the time.

Key benefits

• Removable design: the structure is divided into sections via connecting sleeves, so the cage can be taken out of the car.
• Rear compartment protection: the main hoop with backstays absorbs the loads behind the driver.
• Four welded foot plates: the cage is secured at four bolting points to foot plates that are welded to the bodyshell.
• Heavy-duty tubing: main hoop in E355 steel with a diameter of 45 mm, the rest of the structure in E355 steel of 40 mm.
• Exact fit: AST digitises the bodyshell with laser scanners and designs the cage in 3D for this E34.
• Manufacturer’s figure 71 kg: the weight stated by AST for this version is 71 kg.
• Supplied unpainted: you choose the colour and finish that suit your project.
• Available for cars with and without a sunroof and with and without headlining – you choose this when ordering

Suitable for

BMW 5 Series E34, 4-door saloon

• BMW 5 Series E34 Saloon, built from 1988 to 1996
• Type: half roll cage, version V1
• Drifting, track use and rallying

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN04106
• Rear anchorage: in the rear suspension area
• Rear structure layout: X design
• Type: half roll cage, removable via connecting sleeves
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot plates: 3 mm steel, custom-designed for each car
• Mounting: 4 bolting points on 4 foot plates welded to the bodyshell
• Weight: 71 kg (manufacturer’s figure)
• Finish: welded and unpainted, split into sections via connecting sleeves
• Included: welded structure, connecting sleeves, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. The four foot plates are welded to the bodyshell and the cage is then bolted onto those plates, so have it fitted by someone experienced in welding on a monocoque.

A half roll cage that reinforces the rear compartment of the BMW E34 Saloon and can be taken back out via connecting sleeves.

Why choose this Removable Half Cage E34 Saloon V1?

This V1 is AST’s entry level for the E34 Saloon and focuses entirely on the rear compartment. You get a custom-scanned E355 steel structure without the extra bars of the heavier versions, which keeps fitting and weight manageable. Thanks to the connecting sleeves, the car stays versatile: fit the cage for a track day, remove it for the road.

Frequently asked questions

What exactly will I receive?

You receive the welded structure, the connecting sleeves, the reinforcement plates, the bolts, washers and nuts, the documentation, fitting instructions and a sticker set. The cage is supplied unpainted.

Will this cage fit my car without modification?

AST digitised the bodyshell of the E34 Saloon with laser scanners and then custom-designed the removable half cage E34 Saloon V1 in 3D, so that the tubes and foot plates end up in exactly the right place. The foot plates are, however, welded to the bodyshell; the cage itself is then bolted in.

What if my car has a sunroof or headlining?

When ordering, please state whether your car has a sunroof and whether the headlining will stay in place, and AST will tailor the roll cage accordingly.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
