AST Removable Half Roll Cage BMW E81 V2

The AST Removable Half Roll Cage BMW E81 V2 is a half roll cage for the BMW 1 Series E81 with three-door hatchback bodywork. This removable half cage E81 V2 is more extensively built than the V1, giving the rear compartment of the E81 more rigidity and better load distribution.

The cage is designed and built by AST Roll Cages in Spain, for drivers who spend more time on track than on the road and want to take their E81 further step by step without going straight to a full cage.

Key benefits

• A step above the V1: a more extensive build in the rear compartment, where the V1 is the bare basic version.
• Removable: the sections are joined via connecting sleeves, so you can take the cage out when the car goes back to normal use.
• Four welded foot plates: the four bolting points sit on 3 mm thick foot plates that are custom-designed for each car.
• E355 steel: main hoop with a diameter of 45 mm, the rest of the structure 40 mm.
• Laser scan of each bodyshell: built on a scan of the three-door E81, not derived from another 1 Series.
• Front interior stays intact: the cage is confined to the rear, so the controls and getting in and out remain unchanged.
• Supplied unpainted: ready to be finished in your own colour.

Suitable for

BMW 1 Series E81, three-door hatchback

• BMW 1 Series E81 three-door hatchback, model years 2007 to 2011
• Type: half roll cage, version V2, removable via connecting sleeves
• Drifting, track use and rallying
• Only for the three-door E81. AST designs a separate cage for each body style, so the versions for the E82 coupé and the five-door E87 are not interchangeable with this one.

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN00717
• Sunroof: for roofs without a sunroof
• Headlining: for roofs without headlining
• Rear anchorage: at the wheel arch
• Rear structure layout: X design
• Type: half roll cage, removable via connecting sleeves
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot plates: 3 mm steel, custom-designed for each car
• Mounting: 4 bolting points on 4 foot plates welded to the bodyshell
• Weight: 71 kg (manufacturer’s figure)
• Finish: welded and unpainted, split into sections via connecting sleeves
• Included: welded structure, connecting sleeves, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. Plan the welding of the four foot plates in advance, as they are welded to the floor of the bodyshell before the cage is bolted on. AST digitises the bodyshell with laser scanners and designs the cage in 3D, so that it fits your car exactly.

More rigidity than the V1, with the same advantage: the cage comes out just as easily via the connecting sleeves.

Why choose this removable half cage E81 V2?

If you regularly use your E81 on track or at drift days, you will notice that the rear of a compact hatchback takes a real beating. This version tackles that with a more robust rear structure than the V1, while the connecting sleeves still let you return the car to its original state. The cage is intended for track and competition use; always check the regulations of your own organiser before taking part in an event.

Frequently asked questions

What is the difference from the V1?

The V1 is the bare basic version with the main hoop and braces. The removable half cage E81 V2 is more extensively built and therefore gives more rigidity in the rear compartment. Both sit on four welded foot plates and are removable.

Does this cage also fit a five-door E87?

No. This cage is based on a laser scan of the three-door E81. The five-door E87 and the E82 coupé have a different bodyshell, and AST designs a separate version for them.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
