AST Removable Half Roll Cage BMW E87 V2

The AST Removable Half Roll Cage BMW E87 V2 is a half roll cage for the BMW 1 Series E87 with five-door hatchback bodywork. This removable half cage E87 V2 sits one step above the V1 and is the more heavily equipped level for the E87 within the same range.

The cage is designed and built by AST Roll Cages in Spain for drivers who want more rigidity at the rear of the car without sacrificing the entire interior to a full cage.

Key benefits

• More heavily equipped: one level above the V1 within the same range.
• Can be taken out again: connecting sleeves split the structure into sections.
• Four foot plates: 3 mm steel, custom-designed for each car.
• E355 tube: 45 mm main hoop and 40 mm for the rest of the structure.
• Torsional rigidity: the rear section reacts more calmly when you initiate a drift.
• Interior largely intact: you keep a usable road car.
• Finish it yourself: the cage arrives unpainted.

Suitable for

BMW 1 Series E87, five-door hatchback

• BMW 1 Series E87 five-door hatchback (2004 to 2011)
• Type: half roll cage, version V2
• Not for the E81 three-door or the E82 coupé; AST designs a separate cage for each body style, and these are not interchangeable
• Drifting, track use and rallying

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN00722
• Sunroof: for roofs without a sunroof
• Headlining: for roofs without headlining
• Rear anchorage: at the wheel arch
• Rear structure layout: X design
• Type: half roll cage, removable via connecting sleeves
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot plates: 3 mm steel, custom-designed for each car
• Mounting: 4 bolting points on foot plates welded to the bodyshell
• Weight: 71 kg (manufacturer’s figure)
• Finish: welded and unpainted, in sections via connecting sleeves
• Included: welded structure, connecting sleeves, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. The four foot plates are welded to the bodyshell, and only then is the cage bolted onto them. Have the welding done by someone who knows how to handle thin sheet steel.

More rigidity at the rear of your E87 than with the V1, and still removable from the car in sections.

Why choose this Removable Half Cage E87 V2?

AST scans the bodyshell with laser scanners and designs the cage in 3D, so every tube ends up in exactly the right place. If you mainly use your E87 for track days and drift events, the V2 gives you more rigidity than the base version while the car remains usable. The cage is intended for track and competition use; check your own organiser’s regulations beforehand.

Frequently asked questions

What is the difference from the V1?

The removable half cage E87 V2 is the more heavily equipped level within the same range. The V1 is the entry-level version; both use four bolting points on welded foot plates and can be removed via connecting sleeves.

Does this cage fit an E81 or E82?

No. This cage is designed for the five-door E87. The three-door E81 and the E82 coupé each have their own version at AST with their own dimensions; they are not interchangeable.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
