AST Weld-in Roll Cage BMW E46 Compact V2

The AST Weld-in Roll Cage BMW E46 Compact V2 is a full roll cage for the BMW E46 with 3-door Compact bodywork. In addition to the main hoop and the backstays, this Weld-in E46 Compact V2 also has front reinforcement bars, which extend the structure to the A-pillars and the roof.

The cage is designed and built by AST Roll Cages in Spain, for drivers who want more torsional rigidity than a basic frame offers without closing off the door opening straight away.

Key benefits

• Front reinforcement bars: the cage extends into the A-pillars and ties the front and rear together.
• Noticeably more rigid: the bodyshell flexes less during rapid changes of direction.
• Eight welded mounting points: a permanent, play-free connection to the floor and the pillars.
• E355 steel: 45 mm main hoop, 40 mm for the rest of the structure.
• Still 71 kg: extra rigidity without unmanageable weight.
• Clear door opening: getting in stays easy, as door bars are only added from V3 onwards.
• Unpainted weld-in kit: ready for you to have it blasted or painted.

Suitable for

BMW E46, 3-door Compact

• BMW E46 3-door Compact
• Type: weld-in roll cage, version V2
• Drifting, track use and rallying

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN04706
• Sunroof: for roofs without a sunroof
• Headlining: for roofs without headlining
• Rear anchorage: in the rear suspension area
• Rear structure layout: X design
• Type: full roll cage, weld-in (permanent)
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot plates: 3 mm steel, custom-designed for each car
• Mounting: 8 welded mounting points
• Weight: 71 kg (manufacturer’s figure)
• Finish: unpainted weld-in kit
• Included: weld-in kit, gussets, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. Expect to strip the car, as the front reinforcement bars run along the A-pillars and the interior has to come out there.

With front reinforcement bars extending into the A-pillars, the E46 Compact becomes noticeably more rigid without the door opening getting cluttered.

Why choose this Weld-in E46 Compact V2 roll cage?

V2 is the version where you feel the difference through the steering wheel: thanks to the connection to the front, the bodyshell flexes less and the suspension responds more predictably. AST digitises the bodyshell with laser scanners and designs the cage in 3D, so that every tube sits tight against the panels. A sensible choice for anyone who regularly drives on track but still uses the car on the road.

Frequently asked questions

What does V2 add compared with V1?

The Weld-in E46 Compact V2 adds the front reinforcement bars to the V1 frame, connecting the main hoop to the A-pillars via the roof.

How many welded mounting points does this cage have?

Eight. A multipoint weld-in cage from the same range uses ten welded mounting points and spreads the load over more points on the bodyshell.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
