AST Weld-in Roll Cage BMW E87 V5 NASCAR door

The AST Weld-in Roll Cage BMW E87 V5 NASCAR Door Bars is a full roll cage for the BMW 1 Series E87 with five-door hatchback bodywork. This weld-in E87 V5 NASCAR is the highest specification level in the range: the complete set of bars, combined with several curved tubes in the door instead of the usual door bar.

The cage is designed and built by AST Roll Cages in Spain for teams and drivers who are turning their E87 into a fully fledged competition car and don’t want to do without a single bar.

Key benefits

• Complete set of bars combining all the reinforcements of the lower versions.
• Eight welded mounting points provide a direct connection between cage and bodyshell.
• NASCAR door bars with several curved tubes per door for extra side protection.
• Easier to get in and out than with a straight door bar, which matters on a long race day.
• Maximum torsional rigidity for a chassis that responds more predictably to steering and throttle inputs.
• E355 steel with a 45 mm main hoop and 40 mm for the rest of the structure.
• Foot plates in 3 mm steel, custom-designed for each car.

Suitable for

BMW 1 Series E87, five-door hatchback

• BMW 1 Series E87 five-door hatchback, model years 2004 to 2011
• Type: weld-in roll cage, version V5 with NASCAR door bars
• Not suitable for the three-door E81 or the E82 coupé: AST makes a separate cage for each of those body styles, and they are not interchangeable
• Drifting, track use and rallying

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN03614
• Sunroof: for roofs without a sunroof
• Headlining: for roofs without headlining
• Rear anchorage: in the rear suspension area
• Rear structure layout: V design
• Type: full roll cage, weld-in (permanent)
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot plates: 3 mm steel, custom-designed for each car
• Mounting: 8 welded mounting points on the bodyshell
• Weight: 71 kg (manufacturer’s figure)
• Finish: unpainted weld-in kit
• Included: weld-in kit, gussets, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. AST digitises the bodyshell with laser scanners and designs the cage in 3D so that it fits your car exactly. Expect more welding with this specification level than with a lighter version; plan to strip out the interior and clean the panels before the welder starts.

Choosing the V5 means choosing not the lightest cage but the most rigid one; every bar in the range is included.

Why choose this Weld-in E87 V5 NASCAR roll cage?

The V5 is intended for a car that no longer needs to be used on the road. You get every reinforcement AST designs for this bodyshell in a single welded-in structure, plus the NASCAR door bars that shield the side without eating into your entry space. For an E87 that is driven every weekend, that is the difference between a car that loosens up after one season and one that stays tight.

Frequently asked questions

What is the difference from the V4 version?

The V4 has the door bars, the extra diagonal brace and the harness bar. The V5 goes beyond that with AST’s full set of bars, making it the highest specification level in this range.

Does this cage also fit an E81 or E82?

No. This weld-in E87 V5 NASCAR is designed for the five-door E87. Separate versions exist for the three-door E81 and the E82 coupé; they are not interchangeable.

Is there an FIA homologation for this item?

AST Roll Cages does not list a homologation number for this item. The cage is intended for track and competition use; check in advance what requirements your federation or organiser sets.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
