AST Weld-in Roll Cage BMW E36 Compact V4 NASCAR door

The AST Weld-in Roll Cage BMW E36 Compact V4 with NASCAR door bars is a full roll cage for the BMW E36 with 3-door Compact bodywork. This Weld-in Compact V4 NASCAR has the same layout as the standard V4, with extra diagonal bars and harness bars, but is fitted with NASCAR-style door bars and permanently welded to the bodyshell at 8 points.

The cage is designed and built by AST Roll Cages in Spain, for drivers who want more steel at the sides than a single door bar provides.

Key benefits

• NASCAR-style door bars: the hallmark of this version, with multiple bars filling the door area.
• Harness bars included: your harness gets a mounting point on the cage itself.
• Extra diagonal bars: just as on the standard V4, these make the structure more rigid.
• Permanently welded in: 8 welded mounting points for this weld-in version, compared with 10 on the multipoint variant.
• Chassis-specific design: drawn up around the 3-door Compact bodywork of the E36.
• Unpainted weld-in kit: bare steel, ready to be welded in and then finished to your own taste.
• Built by AST Roll Cages, specialists in custom-made roll cages.

Suitable for

BMW E36, 3-door Compact

• BMW E36 3-door Compact
• Type: weld-in roll cage, version V4 with NASCAR door bars
• Drifting, track use and rallying

Technical specifications

• Manufacturer: AST Roll Cages
• Manufacturer part number: CMBN04183
• Sunroof: for roofs without a sunroof
• Headlining: for roofs without headlining
• Rear anchorage: in the rear suspension area
• Rear structure layout: V design
• Type: full roll cage, weld-in (permanent)
• Main hoop: E355 steel, 45 mm diameter
• Secondary structure: E355 steel, 40 mm diameter
• Foot and reinforcement plates: 3 mm steel, custom-designed for each car
• Mounting: 8 welded mounting points on the bodyshell
• Weight: 71 kg (manufacturer’s figure)
• Finish: unpainted weld-in kit
• Included: weld-in kit, gussets, reinforcement plates, bolts, washers and nuts, documentation, fitting instructions and sticker set

Fitting and delivery

The cage is built to order; the standard delivery time is 15 to 35 working days. AST digitises the bodyshell with laser scanners and designs the cage in 3D, so that it fits your car exactly. Expect the NASCAR door bars to make the entry noticeably narrower, so before the final welding, check that you can get in and out easily wearing a helmet and race suit.

If you want as much steel as possible alongside you, choose the NASCAR door bar version within the V4.

Why choose this Weld-in Compact V4 NASCAR roll cage?

In drifting, side contact is more common than frontal contact, and that is when every tube in the door area counts. The Weld-in Compact V4 NASCAR fills that zone with multiple bars, without leaving out anything from the V4 layout around it. You trade some ease of entry for noticeably more protection right where you sit.

Frequently asked questions

What are NASCAR door bars?

They are multiple tubes that together fill the door area, instead of one or two separate bars. The name comes from American oval racing, where side contact is routine.

Does the rest of the cage differ from the regular V4?

No. The extra diagonal bars and the harness bars are the same; only the layout of the door area is different.

What material is the cage made of?

The main hoop is made of E355 steel with a diameter of 45 mm, and the rest of the structure is E355 steel with a diameter of 40 mm. The supplied foot plates and reinforcement plates are 3 mm thick and custom-designed for each car.

What is the delivery time?

The standard delivery time for this roll cage is 15 to 35 working days.
