Nissan R34 Skyline GTS RWD rear fork (98-01) BC Racing BR coilover kit 8/5 kg/mm

The BC Racing BR coilover kit Skyline R34 rear fork (part number D-18-BR-RS) is a coilover kit adjustable in height and damping, also simply called a coilover, for the Nissan Skyline R34 GTS and GT-t with rear-wheel drive (ER34) and a rear fork mounting of the rear dampers, model years 1998 to 2001. The spring rate is 8 kg/mm front and 5 kg/mm rear.

With the BR series, BC Racing targets the driver who mainly uses the car on the road but also likes to take in the occasional track day or autocross. For the R34 GTS that means: lower, tighter and easier to control, with a suspension you set up yourself. The dampers are monotube with a linear piston, you adjust compression and rebound together in 30 clicks, and you set the ride height via the damper body, independently of the spring preload.

Important with the R34: not every rear-wheel-drive R34 has the same rear damper. On some cars there is a fork at the bottom of the rear damper, a U-shaped bracket with two tabs on either side of the mounting point. Other cars have an eye with a through bolt there. BC Racing therefore makes two kits. This is the rear fork kit; for an eye there is the D-72-BR-RS.

Key benefits

• Rear fork version: for R34s with a fork at the bottom of the rear damper.
• All-round BR tuning: for the road, with room for a track day or autocross.
• Linear monotube: the damping increases evenly with the speed of the wheel movement.
• 30 positions on one knob: compression and rebound adjustable at the same time.
• Height independent of the spring preload: lowering via the damper body.
• Patented concave lock ring: at the bottom of the damper, for a securely locked height.
• 8/5 kg/mm: 8 kg/mm front, 5 kg/mm rear.
• Rubber top mounts at the front: at the rear, rubber or the original mounting remains.
• Rebuildable: the dampers can be rebuilt.

Suitable for

Nissan Skyline R34 GTS and GT-t with rear-wheel drive (ER34), model years 1998 to 2001, with a fork as the lower mounting of the rear damper (rear fork). Not for R34s with rear eye dampers and not for the four-wheel-drive R34, such as the GT-R.

• Sporty everyday use
• A track day or autocross in between
• Lowering and setting up the damping yourself

Technical specifications

• Manufacturer: BC Racing
• Part number: D-18-BR-RS
• Series: BR, all-round for the road and the occasional circuit outing
• Version: rear fork, the rear damper has a fork as its lower mounting
• Spring rate front/rear: 8/5 kg/mm
• Damper design: monotube with linear piston
• Damping: 30 clicks, compression and rebound adjustable simultaneously
• Ride height: fully adjustable via the damper body, independent of the spring preload
• Top mounts: rubber top mounts at the front, rubber or the original mounting at the rear (BC code RS)
• Contents: dampers and springs front and rear, lower mounts, top mounts where applicable, adjustment spanners and warranty card with serial number
• Warranty: 1 year on manufacturing defects

Fitting and delivery

This BR kit is made specifically for the R34 with rear fork dampers and replaces the original dampers and springs. So first check under the car whether there is a fork at the bottom of the rear damper. Preferably have the kit fitted by an experienced mechanic and book a wheel alignment straight afterwards, because a different ride height changes camber and toe. As long as the manufacturer has stock, the delivery time is 1 to 2 weeks. If the kit is temporarily sold out, you can still order it and we will let you know when it arrives.

BC Racing makes the BR for the rear-wheel-drive Skyline R34 in a rear eye and a rear fork version, and this D-18-BR-RS is the version for rear dampers with a fork.

Why choose this BR coilover kit Skyline R34 rear fork?

The rear-wheel-drive R34 is a car that many owners like to work on themselves, and the suspension is often the first thing to be tackled. With this kit you decide the ride height and the stiffness of the damping yourself, while the car remains pleasant on ordinary roads. Because BC Racing makes the kit specifically for the rear fork version, the rear damper connects to the mounting your car already has.

BC Racing coilover kits for the Nissan Skyline R34 GTS (RWD) with rear fork dampers

Overview of the BC Racing series for the Nissan Skyline R34 GTS (RWD) with rear fork dampers supplied by Race4DriftParts, with the BC Racing part number. Spring rates in kg/mm, front/rear.

For the Nissan Skyline R34 GTS (RWD) with rear eye dampers, BC Racing has separate kits. Their part numbers start with D-72.

Frequently asked questions

How do I recognise a rear fork damper on my Nissan Skyline R34 for the BC Racing BR?

By a U-shaped fork at the bottom of the rear damper, with two tabs on either side of the mounting point. If you see that, the BR coilover kit Skyline R34 rear fork (D-18-BR-RS) is the right one. If there is a round eye with a through bolt, you need the D-72-BR-RS. If you are not sure, contact us before you order.

Does the BC Racing BR for the Skyline R34 rear fork also fit a four-wheel-drive R34?

No. BC Racing lists this kit for the R34 GTS and GT-t with rear-wheel drive from 1998 to 2001, with rear fork dampers. For the GT-R R33 and R34 there is a separate BR with part number D-08-BR-RS.

What is the difference between the BC Racing BR and DS for the Skyline R34 GTS rear fork?

The difference is in the piston: the BR damps linearly, the DS digressively. As a result, the DS damps more firmly at slow movements and is a better match for an R34 that is often driven on the circuit. For the rear fork version both have 8/5 kg/mm.

How long does delivery of the BC Racing BR coilover kit for the Skyline R34 rear fork take?

Normally 1 to 2 weeks as long as the manufacturer has stock. If BC Racing is briefly out of the kit, you can still order it and we will keep you informed.
