BMW E36 3 Series Compact True Rear (94-00) BC Racing ER coilover kit 5/5 kg/mm

The BC Racing ER coilover kit E36 Compact True Rear (part number I-79-ER) is a coilover kit adjustable in height and damping, also simply called a coilover, for the BMW 3 Series E36 Compact (E36/5), model years 1994 to 2000, in True Rear version. The spring rate is 5 kg/mm front and 5 kg/mm rear.

This kit combines 2-way adjustable dampers with external reservoirs with a complete strut at the rear. As standard, the Compact has a separate spring and a separate damper at the rear, in different places in the suspension. In this True Rear version, this is replaced by a complete coilover strut with the spring around the damper.

As a result, you adjust the rear ride height in the same way as at the front, on the strut itself, and spring and damper work on the same point at the rear. The ER series is built for serious track work and competition: you set compression and rebound separately in 30 clicks each, and the dual-piston monotube dampers with reservoir and fully synthetic oil keep the damping constant, even after long sessions.

The spring rate is 5/5 kg/mm, the same front and rear.

Key benefits

• Complete strut at the rear: the spring sits around the damper, instead of a separate spring and damper.
• Independent compression and rebound: 30 clicks each per damper.
• Dual-piston with external reservoir: built for serious track work and competition.
• Digressive characteristic: the chassis stays calm, the wheels stay compliant.
• Oil with ultra-high viscosity index: fully synthetic, little fade when hot.
• Camber plates: rubber top mounts as an option, check valve optional.
• Spring rate 5/5 kg/mm: balanced for the True Rear layout.
• Rebuildable: remains serviceable for several seasons.

Suitable for

BMW 3 Series Compact E36/5, model years 1994 to 2000, in True Rear version

• Competition and serious track days
• Drifting with long runs
• Drivers who want the same adjustment options at the rear as at the front

Technical specifications

• Manufacturer: BC Racing
• Part number: I-79-ER
• Series: ER, 2-way with external reservoir
• Version: True Rear, complete strut at the rear (spring around the damper)
• Spring rate front/rear: 5/5 kg/mm
• Damper design: dual-piston monotube with external reservoir, digressive
• Damping: 2-way, 30 clicks compression and 30 clicks rebound, independent
• Ride height: infinitely adjustable via the damper body
• Top mounts: camber plates, rubber top mounts optional; check valve optional
• Contents: 4 struts with dampers and springs, lower mounts, top mounts where applicable, adjustment spanners and warranty card with serial number
• Warranty: 1 year on manufacturing defects. Noise is not covered by the warranty

Fitting and delivery

When fitting, new struts go in at the front and at the rear a coilover strut replaces the separate spring and damper. Please note: BC Racing requires the body shell to be reinforced before fitting a True Rear kit. We recommend having it fitted by an experienced mechanic; route the reservoir lines so that they do not rub anywhere and have the car aligned after fitting. The delivery time is 1 to 2 weeks as long as the manufacturer has stock. If the kit is not in stock, simply order it and we will keep you informed.

A Compact with reservoir dampers and a complete strut at the rear: each axle adjustable separately, session after session.

Why choose this ER coilover kit E36 Compact True Rear?

Because you get two improvements in one kit here: the separate compression and rebound adjustment of the ER, and a rear axle that you set up just as directly as the front. That makes the Compact more consistent in fast corners and more predictable when you get on the power.

BC Racing coilover kits for the BMW E36 Compact True Rear

Overview of the BC Racing series for the BMW E36 Compact True Rear supplied by Race4DriftParts, with the BC Racing part number. Spring rates in kg/mm, front/rear.

For the standard version without True Rear, BC Racing has separate kits for the E36 Compact. Their part numbers start with I-25.

Frequently asked questions

What is the difference between the BC Racing ER True Rear and the standard ER for the E36 Compact?

The ER coilover kit E36 Compact True Rear (I-79-ER) has a complete strut at the rear and a spring rate of 5/5 kg/mm. The standard ER (I-25-ER) keeps a separate spring and separate damper at the rear and has 6/8 kg/mm.

When do you choose the BC Racing ZX instead of the ER for the E36 Compact True Rear?

Choose the ZX if you want to fine-tune even further: the ZX is 3-way and also splits the compression into low and high speed. The ER is 2-way, with compression and rebound separate.

Is there a less expensive BC Racing True Rear kit for the E36 Compact?

Yes, without reservoirs there is the DS True Rear for the Compact, which we also have in the shop. It adjusts compression and rebound together with one knob.

Does this BC Racing ER coilover kit E36 Compact True Rear also fit an E36 Sedan, Coupe or Touring?

No. This kit is only intended for the E36 Compact (E36/5), model years 1994 to 2000. For the E36 Sedan, Coupe, Convertible and Touring in True Rear version, BC Racing has separate kits with part numbers starting with I-30.

What is the delivery time of this BC Racing ER coilover kit?

The delivery time is 1 to 2 weeks as long as the manufacturer has stock. Otherwise you can still order and we will let you know when it comes in.
